Mackie 1604VLZ4 16-Channel 4-Bus Compact Mixer

visitors are viewing

Mackie 1604VLZ4 16-Channel 4-Bus Compact Mixer

$892.49 ~~$1,049.99~~

In Stock -

Write a Review

Quantity:

- +

Add to Wishlist Added to Wishlist

Ask us any Question

Details

SKU: 663961039818
Brand: Mackie
Type: Live Sound
Availability: In Stock

Description

The Mackie 1604VLZ4 16-Channel 4-Bus Compact Mixer includes a combination of Onyx preamps and a high-headroom / low-noise design. All 16 channels feature an Onyx microphone preamplifier, line input and insert in a compact 4-bus design built for application flexibility and professional performance.

The mixer is built-like-a-tank with a rugged solid-steel chassis and high-contrast controls for tactile control. It is a band-friendly analog mixer used in professional broadcast and post facilities.

16-Channel mixer featuring high-headroom, low-noise design

16 Boutique-Quality Onyx Microphone Preamps:
Wide 60 dB gain range
128.5 dB dynamic range
+22 dBu line input handling
Extended frequency response
Distortion under 0.0007% (20 Hz to 50 kHz)

Improved RF rejection, suitable for broadcast applications

Phantom power for condenser microphones

16 high-headroom line inputs with +4 / -10 operation control

16 balanced inserts suitable for integrating outboard gear

3-band EQ with sweepable midrange

18 dB/octave 75 Hz low-cut filter on microphone input channels

Four AUX sends, level, pan and solo and overload / mute LEDs on each channel

Four stereo returns, eight direct outs and four group / bus outputs

60mm long-wearing log-taper faders

Control room / phones multi-input source matrix

High-resolution 12-segment stereo meters

Sealed rotary controls resist dust and grime

Built-like-a-tank rugged steel chassis with powder-coat finish

High-visibility, high-contrast controls deliver convenient at-a-glance visual feedback

Rack-mountable design with 3 physical configurations via Rotopod accessory (sold separately)

Multi-voltage power supply for worldwide use

Applications: Live sound mixing, houses of worship, clubs, gymnasiums, banquet halls, conference rooms, boardrooms, multi-track studio and field recording, video post-production, multimedia applications, broadcast, and many more
